Heated and cooled cup holder circuit for Audi Q5 II (2016-2020)
Heated and cooled cup holder circuit
BRN WIRE
COMPUTER DATA LINES SYSTEM
CUP HOLDER W/ HEATING, COOLING ELEMENT
CUPHOLDER AMBIENT LIGHTING LAMP
CUPHOLDER COOLING ELEMENT BUTTON
CUPHOLDER COOLING INDICATOR LAMP
CUPHOLDER HEATING ELEMENT BUTTON
CUPHOLDER HEATING INDICATOR LAMP
FUSE 9
FUSE PANEL 3
FUSE PANEL F
HOT AT ALL TIMES
LEFT CUPHOLDER ILLUMINATION BULB
RED/BLU WIRE
RELAY & FUSE PANEL 2
RIGHT CUPHOLDER ILLUMINATION BULB
VIO/RED WIRE
