Car Wiring Diagrams for Charging circuit for Audi Q5 I (2008-2012)

BATTERY BATTERY INTERRUPT IGNITER BATTERY JUMP START TERMINAL BATTERY MONITORING CONTROL MODULE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DATA BUS ON BOARD DIAGNOSTIC INTERFACE FUSE PANEL SA GENERATOR, VOLTAGE REGULATOR INSTRUMENT CLUSTER CONTROL MODULE ORG/BLU WIRE ORG/BRN WIRE RED WIRE RED/BRN WIRE STARTER SUPPLEMENTAL RESTRAINTS SYSTEM VIO/BLU WIRE WHT WIRE
