Radio circuit, premium mmi for Audi Q5 I (2008-2012)

1 2 MOST DATA BUS CIRCUIT ALARM ANTENNA ANTENNA 2 ANTENNA 2 RADIO ANTENNA AMPLIFIER (REAR OF CARGO AREA) ANTENNA AMPLIFIER 3 (W/ TV TUNER) ANTENNA AMPLIFIER 4 ANTI-THEFT BLK/GRN WIRE BRN WIRE CD/DVD CHANGER CENTRAL COMFORT SYSTEM CENTRAL CONTROL COMPUTER DATA LINES SYSTEM FUSE 1 FUSE 5 FUSE CARRIER 2 FUSE CARRIER 5 FUSE FUSE 6 CARRIER FUSE PANEL SD GRN/VIO WIRE HOT AT ALL TIMES HOT W/ SOCKETS RELAY ENERGIZED INFORMATION ELECTRONICS CONTROL MODULE 1 (CENTER OF DASH) LOCKING, MODULE (LEFT SIDE OF TRUNK) MOST DATA BUS CIRCUIT MULTIMEDIA ON DRIVER SEAT MULTIMEDIA ON PASSENGER SEAT NAVIGATION NCA WIRE PHASED IN MODIFICATION RADIO RED/BLK WIRE RED/VIO WIRE RED/YEL WIRE RELAY/FUSE PANEL SF (RIGHT SIDE OF LUGGAGE COMPT) ROOF ANTENNA SATELLITE SYSTEM TELEPHONE TELEPHONE BASE PLATE TV ANTENNA 1 TV ANTENNA 3 TV TUNER

BLK WIRE BLK/WHT WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CENTER MID/ HIGH RANGE SPEAKER COMPUTER DATA LINES SYSTEM DIGITAL SOUND SYSTEM CONTROL MODULE FUSE 3 FUSE CARRIER 5 GRN/VIO WIRE HOT AT ALL TIMES INSIDE MICROPHONE LEFT FRONT BASS SPEAKER LEFT FRONT MIDRANGE SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR MID/ LOW RANGE SPEAKER LEFT REAR MIDRANGE SPEAKER LEFT REAR TREBLE SPEAKER MICROPHONE UNIT MOST DATA BUS CIRCUIT NCA WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY/FUSE PANEL SF (RIGHT SIDE OF LUGGAGE COMPT) RIGHT FRONT BASS SPEAKER RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR MID/ LOW RANGE SPEAKER RIGHT REAR MIDRANGE SPEAKER RIGHT REAR TREBLE SPEAKER SUBWOOFER WHT WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE
