Memory systems circuit for Audi Q5 I (2008-2012)

BACKREST BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR/SENSOR (MOTOR: DRIVER'S SEAT BACK) DRIVER POWER DRIVER SEAT HEIGHT ADJUSTMENT MOTOR/SENSOR (UNDER REAR OF SEAT) DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR (DRIVER'S SEAT BACK) DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR (DRIVER'S SEAT BACK) DRIVER'S SEAT ADJUSTMENT CONTROL HEAD DRIVER'S SEAT FORE/AFT ADJUSTMENT MOTOR/SENSOR DRIVER'S SEAT INCLINATION/ TILT ADJUSTMENT MOTOR/SENSOR DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH FORE/AFT GRN WIRE GRN/BLK WIRE HEIGHT HOT AT ALL TIMES MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE (BELOW DRIVER'S SEAT) ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SEAT ADJUSTMENT CIRCUIT BREAKER 1 SEATS SYSTEM TILT YEL WIRE YEL/GRN WIRE

BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DAY/NIGHT DRIVER'S DOOR CONTROL MODULE (DRIVER'S DOOR) DRIVER'S EXTERIOR MIRROR ASSEMBLY DRIVER'S SEAT MEMORY PROGRAM CONTROL HEAD FOLD-IN FUSE 11 FUSE 8 FUSE CARRIER 2 FUSE PANEL SC GRN/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HEATER HORIZONTAL HOT AT ALL TIMES LANE CHANGE LOCK OUT BUTTON NAVIGATION SYSTEM NCA WIRE ORG/BRN WIRE ORG/GRN WIRE POSITION 1 BUTTON POSITION 2 BUTTON POWER DISTRIBUTION SYSTEM RED WIRE RED/GRN WIRE RED/YEL WIRE SIGNAL LAMP VERTICAL WHT WIRE WHT/YEL WIRE YEL WIRE

9 10 11 5 8 16 14 4 13 7 PNK WIRE ADJUSTING SWITCH BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DAY/NIGHT FOLD AWAY SWITCH FOLD-IN FRONT PASSENGER'S DOOR CONTROL MODULE (FRONT PASSENGER DOOR) FRONT PASSENGER'S EXTERIOR MIRROR ASSEMBLY FUSE 11 FUSE 9 FUSE CARRIER 3 GRY/WHT WIRE GRY/YEL WIRE HEATER HORIZONTAL HOT AT ALL TIMES LANE CHANGE MIRROR ADJUSTMENT SWITCH ASSEMBLY NAVIGATION SYSTEM NCA WIRE ORG/BRN WIRE ORG/GRN WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY/ FUSE PANEL SF (RIGHT SIDE OF LUGGAGE COMPT) SELECTOR SWITCH SIGNAL LAMP VERTICAL WHT WIRE WHT/YEL WIRE YEL WIRE
