Electronic suspension circuit for Audi Q5 I (2008-2012)

BLK WIRE BLU WIRE BRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC DAMPING CONTROL MODULE (RIGHT SIDE OF LUGGAGE COMPT) FUSE 12 FUSE 2 FUSE 6 FUSE CARRIER 2 FUSE CARRIER 4 FUSE PANEL SD GRN/BRN WIRE GRN/GRY WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED LEFT FRONT DAMPENING ADJUSTMENT VALVE LEFT REAR DAMPENING ADJUSTMENT VALVE ORG/BLK WIRE ORG/BRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY/FUSE PANEL SF (RIGHT SIDE OF LUGGAGE COMPARTMENT) RIGHT FRONT DAMPENING ADJUSTMENT VALVE RIGHT FRONT LEVEL CONTROL SYSTEM SENSOR (RIGHT FRONT CONTROL ARM) RIGHT REAR DAMPENING ADJUSTMENT VALVE VIO/GRN WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE WHT/BRN WIRE WHT/GRY WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE

BLK WIRE BRN WIRE BRN/GRY WIRE CHARISMA SWITCH MODULE COMPUTER DATA LINES SYSTEM FUSE CARRIER 3 FUSE FUSE PANEL SC GRN/BRN WIRE GRN/GRY WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT BODY ACCELERATION SENSOR (LEFT FRONT BODY) LEFT FRONT LEVEL CONTROL SYSTEM SENSOR (LEFT FRONT CONTROL ARM) LEFT REAR LEVEL CONTROL SYSTEM SENSOR (LEFT REAR CONTROL ARM) ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/WHT WIRE REAR BODY ACCELERATION SENSOR (LEFT REAR OF BODY) RED/GRY WIRE RED/VIO WIRE RIGHT FRONT BODY ACCELERATION SENSOR (RIGHT FRONT BODY) RIGHT REAR LEVEL CONTROL SYSTEM SENSOR (RIGHT REAR CONTROL ARM) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) VIO WIRE VIO/GRN WIRE VIO/RED WIRE VIO/YEL WIRE W/O NAVIGATION SYSTEM W/ NAVIGATION SYSTEM WHT WIRE WHT/BRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL/BLK WIRE YEL/GRY WIRE YEL/WHT WIRE
