Audi Q5 I (2008-2012) range speaker wiring diagram
This page shows the only wiring diagram for the component.range speaker, which is found in the car Audi Q5 I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
range speaker wiring diagram (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CENTER MID/HIGH RANGE SPEAKER
COMPUTER DATA LINES SYSTEM
DIGITAL SOUND SYSTEM CONTROL MODULE
FRONT INFORMATION DISPLAY CONTROL HEAD (W/ RADIO CONCERT OR SYMPHONY)
FUSE 3
FUSE CARRIER
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT MID-BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR MID/LOW RANGE SPEAKER
LEFT REAR TREBLE SPEAKER
ORG/BRN WIRE
ORG/VIO WIRE
PNK WIRE
RADIO
RANGE SPEAKER
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY/ FUSE PANEL SF (RIGHT SIDE OF LUGGAGE COMPT)
RIGHT FRONT MID-BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID/LOW
RIGHT REAR TREBLE SPEAKER
SUBWOOFER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Radio circuit, standard infotainment (2 of 2) -> RANGE SPEAKER
