Audi Q5 I (2008-2012) mmi high Wiring diagram
This page shows the only wiring diagram for the component.mmi high, which is found in the car Audi Q5 I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mmi high (1 of 1)
18 PIN CONNECTOR
BLK WIRE
BLU WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT INFORMATION DISPLAY CONTROL HEAD
FUSE CARRIER 2 FUSE 3
FUSE CARRIER 5 FUSE 4
FUSE PANEL SD
GRN WIRE
GRN/VIO WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1 (CENTER OF DASH)
LEFT FRONT RIGHT FRONT MICROPHONE MICROPHONE
MICROPHONE UNIT
MMI BASIC
MMI BASIC MMI HIGH
MMI HIGH
MOST DATA BUA CIRCUIT
MULTIMEDIA CONTROL HEAD
NCA WIRE
ORG/ WIRE
REAR VIEW CAMERA SYSTEM CONTROL MODULE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY/FUSE PANEL SF (RIGHT SIDE OF LUGGAGE COMPT)
TV TUNER
VIO/YEL WIRE
W/ CELLULAR TELEPHONE PREPARATION W/O HANDS-FREE SPEAKING SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Multimedia interface circuit (1 of 2) -> MMI HIGH
