Audi Q5 I (2008-2012) front passenger's seat backrest blower fan wiring diagram
This page shows the only wiring diagram for the component.front passenger's seat backrest blower fan, which is found in the car Audi Q5 I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front passenger's seat backrest blower fan wiring diagram (1 of 1)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S BACKREST HEATING ELEMENT
DRIVER'S SEAT BACKREST BLOWER FAN
DRIVER'S SEAT BACKREST BLOWER FAN 2
DRIVER'S SEAT CUSHION BLOWER FAN
DRIVER'S SEAT CUSHION BLOWER FAN 2
DRIVER'S SEAT HEATER
FRONT PASSENGER'S BACKREST HEATING ELEMENT
FRONT PASSENGER'S SEAT BACKREST BLOWER FAN
FRONT PASSENGER'S SEAT BACKREST BLOWER FAN 2
FRONT PASSENGER'S SEAT CUSHION BLOWER FAN
FRONT PASSENGER'S SEAT CUSHION BLOWER FAN 2
FRONT PASSENGER'S SEAT HEATER
FUSE
FUSE CARRIER 2
FUSE CARRIER 3
FUSE PANEL SC
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT VENTILATION CONTROL MODULE
LEFT FRONT SIDE BOLSTER HEATER SEAT TEMP SENSOR
LUGGAGE COMPT)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RELAY/ FUSE PANEL SF (RIGHT SIDE OF
RIGHT FRONT SEAT VENTILATION CONTROL MODULE
RIGHT FRONT SIDE BOLSTER HEATER SEAT TEMP SENSOR
SEAT HEATING ELEMENT
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Front heated seats circuit, without memory seats with ventilation -> FRONT PASSENGER'S SEAT BACKREST BLOWER FAN
