Audi Q5 I (2008-2012) front passenger's exterior mirror assembly Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger's exterior mirror assembly, in which he is found in the car Audi Q5 I (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger's exterior mirror assembly (1 of 3)
BLK/BRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DIRECTIONAL STABILIZATION ASSISTANCE CONTROL MODULE
DIRECTIONAL STABILIZATION ASSISTANCE WINDSHIELD HEATER
DRIVER'S EXTERIOR MIRROR ASSEMBLY
FRONT PASSENGER'S EXTERIOR MIRROR ASSEMBLY
FUSE 10
FUSE CARRIER 1 FUSE 4
FUSE CARRIER 4
FUSE PANEL SC
GRY/BLU WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LANE CHANGE
LANE CHANGE ASSISTANCE BUTTON
LANE CHANGE ASSISTANCE CONTROL MODULE (LEFT REAR CARGO AREA)
LANE CHANGE ASSISTANCE CONTROL MODULE 2 (RIGHT REAR CARGO COMPT)
LUGGAGE COMPT)
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRY WIRE
RELAY/FUSE PANEL SF (RIGHT SIDE OF
VIO/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Lane departure warning circuit -> FRONT PASSENGER'S EXTERIOR MIRROR ASSEMBLY
Wiring diagram front passenger's exterior mirror assembly (2 of 3)
9 10 11 5 8 16 14 4 13 7 PNK WIRE
ADJUSTING SWITCH
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DAY/NIGHT
FOLD AWAY SWITCH
FOLD-IN
FRONT PASSENGER'S DOOR CONTROL MODULE (FRONT PASSENGER DOOR)
FRONT PASSENGER'S EXTERIOR MIRROR ASSEMBLY
FUSE 11
FUSE 9
FUSE CARRIER 3
GRY/WHT WIRE
GRY/YEL WIRE
HEATER
HORIZONTAL
HOT AT ALL TIMES
LANE CHANGE
MIRROR ADJUSTMENT SWITCH ASSEMBLY
NAVIGATION SYSTEM
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY/ FUSE PANEL SF (RIGHT SIDE OF LUGGAGE COMPT)
SELECTOR SWITCH
SIGNAL LAMP
VERTICAL
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Memory systems circuit (3 of 3) -> FRONT PASSENGER'S EXTERIOR MIRROR ASSEMBLY
Wiring diagram front passenger's exterior mirror assembly (3 of 3)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DAY/NIGHT
FOLD-IN
FRONT PASSENGER'S DOOR CONTROL MODULE (FRONT PASSENGER DOOR)
FRONT PASSENGER'S EXTERIOR MIRROR ASSEMBLY
FUSE 11
FUSE 9
FUSE CARRIER 3
GRY/WHT WIRE
GRY/YEL WIRE
HEATER
HORIZONTAL
HOT AT ALL TIMES
LANE CHANGE
NAVIGATION SYSTEM (LANE CHANGE ASSISTANCE CIRCUIT)
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY/ FUSE PANEL SF (RIGHT SIDE OF LUGGAGE COMPT)
SIGNAL LAMP
VERTICAL
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Power mirrors circuit (2 of 2) -> FRONT PASSENGER'S EXTERIOR MIRROR ASSEMBLY
