Anti-lock brakes circuit for Audi Q5 Sportback FY (2020-2024)

ABS CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) ABS CONTROL MODULE FUSE 1 ABS CONTROL MODULE FUSE 2 ABS HYDRAULIC PUMP ABS HYDRAULIC UNIT BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLK/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 1 DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 2 DRIVING DYNAMICS REGULATION SWITCH VALVE 1 DRIVING DYNAMICS REGULATION SWITCH VALVE 2 FUSE 11 FUSE PANEL 2 FUSE PANEL B GRN WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT ABS INLET VALVE LEFT FRONT ABS OUTLET VALVE LEFT FRONT ABS WHEEL SPEED SENSOR LEFT REAR ABS INLET VALVE LEFT REAR ABS OUTLET VALVE LEFT REAR ABS WHEEL SPEED SENSOR PNK WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 RIGHT FRONT ABS INLET VALVE RIGHT FRONT ABS OUTLET VALVE RIGHT FRONT ABS WHEEL SPEED SENSOR RIGHT PARKING BRAKE MOTOR RIGHT REAR ABS INLET VALVE RIGHT REAR ABS OUTLET VALVE RIGHT REAR ABS WHEEL SPEED SENSOR SUPPLEMENTAL RESTRAINTS SYSTEM VACUUM SENSOR WHT WIRE YEL WIRE

ASR/ESP BUTTON AUTO HOLD BUTTON AUTO- HOLD BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BULB COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT 1 FUSE 3 FUSE 6 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL B GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES ILLUMINATION INDICATOR LAMP INSTRUMENT CLUSTER SYSTEM LEFT PARKING BRAKE MOTOR ORG/BRN WIRE ORG/GRN WIRE PUSH BUTTON RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RELAY & FUSE PANEL 1 ROOF RACK RECOGNITION SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE YEL WIRE

3.0L TURBO ABS INDICATOR BLK WIRE BRAKE BOOSTER BRAKE FLUID LEVEL WARNING SWITCH BRAKE LAMP SWITCH BRAKE SYSTEM INDICATOR BRN WIRE BRN/BLU WIRE BULB COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DISPLAY UNIT ELECTRO- MECHANICAL ELECTRO- MECHANICAL PARKING BRAKE BUTTON ENGINE/MOTOR CONTROL MODULE FUSE 1 FUSE 11 FUSE 5 FUSE 9 FUSE PANEL 1 FUSE PANEL B FUSE PANEL C GRN WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED ILLUMINATION INDICATOR LAMP INSTRUMENT CLUSTER CONTROL MODULE N/A ORG/BRN WIRE ORG/VIO WIRE PARKING BRAKE PNK WIRE POWER DISTRIBUTION SYSTEM PUSH BUTTON RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 TOWING RECOGNITION CONTROL MODULE VIO/RED WIRE WIRE JUNCTION YEL WIRE
