Audi Q5 e-tron I (2022-2024) w/ panorama sunroof Wiring diagram
This page shows the only wiring diagram for the component.w/ panorama sunroof, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ panorama sunroof (1 of 1)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT ROOF MODULE
FUSE 4
FUSE 8
FUSE PANEL 2
FUSE PANEL 3
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
ORG/ WIRE
ORG/BRN WIRE
REAR ROOF FUNCTION BUTTON
RED WIRE
RED/BLK WIRE
RELAY & FUSE PANEL 1
SUNROOF CONTROL MODULE
SUNROOF MOTOR (FRONT OF SUNROOF ASSEMBLY)
SUNROOF SHADE MOTOR
VIO WIRE
VIO/RED WIRE
W/ PANORAMA SUNROOF
WHT WIRE
WINDOW SHADE, SUNROOF BUTTON
YEL WIRE
Go to component -> Power top/sunroof circuit -> W/ PANORAMA SUNROOF
