Audi Q5 e-tron I (2022-2024) trailer hitch indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.trailer hitch indicator lamp, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer hitch indicator lamp (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
EXTERIOR LAMPS CIRCUIT
FUSE 5
FUSE 7
FUSE 8
FUSE 9
FUSE PANEL 5
FUSE PANEL F
GRY/BLK WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LOADING SILL LOWERING CONTROL HEAD
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY & FUSE PANEL 2
SUPPLEMENTAL RESTRAINTS SYSTEM
SWITCH ILLUMINATION BULB
TOWING RECOGNITION CONTROL MODULE
TRAILER HITCH INDICATOR LAMP
TRAILER HITCH RELEASE BUTTON
VIO/WHT WIRE
WHT/RED WIRE
YEL/VIO WIRE
Go to component -> Trailer tow circuit (1 of 2) -> TRAILER HITCH INDICATOR LAMP
