Audi Q5 e-tron I (2022-2024) sunlight photo sensor Wiring diagrams

AIR DISTRIBUTION DOOR MOTOR BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF DEFROSTER DOOR MOTOR DISPLAY UNIT DRIVER SIDE SEAT VENTILATION SWITCH EVAPORATOR VENT TEMPERATURE SENSOR FRESH AIR DOOR MOTOR FRONT A/C DISPLAY CONTROL HEAD FRONT PASSENGER SIDE SEAT VENTILATION SWITCH 2 FUSE 12 FUSE 6 FUSE PANEL 2 FUSE PANEL B FUSE PANEL C GRN/YEL WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HOT AT ALL TIMES HUMIDITY SENSOR INSTRUMENT CLUSTER CONTROL MODULE LEFT FOOTWELL VENT TEMPERATURE SENSOR LEFT SEAT HEATING BUTTON ORG/BLK WIRE ORG/BRN WIRE ORG/VIO WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR RECIRCULATION DOOR MOTOR RED WIRE RED/BRN WIRE RELAY & FUSE PANEL 1 RIGHT FOOTWELL VENT TEMPERATURE SENSOR RIGHT SEAT HEATING BUTTON SUNLIGHT PHOTO SENSOR TEMPERATURE CONTROL DOOR MOTOR VIO/WHT WIRE WHT WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF DEFROSTER DOOR MOTOR DISPLAY UNIT DRIVER SIDE SEAT VENTILATION SWITCH FRESH AIR DOOR MOTOR FRONT A/C DISPLAY CONTROL HEAD FRONT PASSENGER SIDE SEAT VENTILATION SWITCH 2 FUSE 12 FUSE 6 FUSE PANEL 2 FUSE PANEL B FUSE PANEL C GRN/YEL WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HOT AT ALL TIMES HUMIDITY SENSOR INSTRUMENT CLUSTER CONTROL MODULE LEFT SEAT HEATING BUTTON LEFT SIDE VENT ADJUSTMENT MOTOR LEFT TEMPERATURE CONTROL DOOR MOTOR ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/VIO WIRE ORG/WHT WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR REAR AIR DISTRIBUTION DOOR MOTOR REAR TEMPERATURE CONTROL DOOR MOTOR RECIRCULATION DOOR MOTOR RED WIRE RED/BRN WIRE RELAY & FUSE PANEL 1 RIGHT SEAT HEATING BUTTON RIGHT SIDE VENT ADJUSTMENT MOTOR RIGHT TEMPERATURE CONTROL DOOR MOTOR SUNLIGHT PHOTO SENSOR VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

AUTOMATIC DIMMING EXTERIOR REAR VIEW MIRROR AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF DRIVER DOOR CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FUSE 1 FUSE 12 FUSE 14 FUSE 5 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL 4 FUSE PANEL B GROUND DISTRIBUTION SYSTEM HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED HUMIDITY SENSOR LEFT FRONT DOOR COUPLING POINT LIGHT RECOGNITION SENSOR ORG/BRN WIRE ORG/GRN WIRE ORG/GRY WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR RED WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RELAY & FUSE PANEL 1 RIGHT FRONT DOOR COUPLING POINT SUNLIGHT PHOTO SENSOR VIO/RED WIRE VIO/WHT WIRE W/ HIGH BEAM ASSIST W/O HIGH BEAM ASSIST

AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR BLK WIRE BLK/VIO WIRE BLU WIRE BRN WIRE BRN/BLU WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF DISPLAY UNIT FUSE 1 FUSE 10 FUSE 12 FUSE 14 FUSE 2 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL 4 FUSE PANEL B FUSE PANEL C FUSE PANEL F GRN WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE GRY/WHT WIRE HEADLAMP WASHER SYSTEM PUMP HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED HUMIDITY SENSOR INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT CLUSTER SYSTEM LIGHT RECOGNITION SENSOR LIGHT SWITCH ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR REAR WINDOW WIPER MOTOR RED WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RELAY & FUSE PANEL 1 RELAY & FUSE PANEL 2 STEERING COLUMN ELECTRONICS CONTROL MODULE SUNLIGHT PHOTO SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/RED WIRE VIO/WHT WIRE W/ HIGH BEAM ASSIST W/O HIGH BEAM ASSIST WHT WIRE WHT/VIO WIRE WINDSHIELD PROJECTION HEAD-UP DISPLAY BUTTON WINDSHIELD WASHER FLUID LEVEL SENSOR WINDSHIELD WASHER PUMP WINDSHIELD WIPER INTERMITTENT MODE SWITCH WINDSHIELD WIPER MOTOR WINDSHIELD WIPER SWITCH WIPER MOTOR CONTROL MODULE YEL WIRE YEL/RED WIRE
