Audi Q5 e-tron I (2022-2024) steering column vertical adjustment sensor Wiring diagram
This page shows the only wiring diagram for the component.steering column vertical adjustment sensor, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column vertical adjustment sensor (1 of 1)
BLK/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 15
FUSE PANEL C
GRN/BLK WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
POWER ADJUSTABLE STEERING COLUMN CONTROL MODULE
RED WIRE
STEERING COLUMN ADJUSTMENT SWITCH
STEERING COLUMN AXIAL ADJUSTMENT SENSOR
STEERING COLUMN FORWARD/BACK ADJUSTMENT MOTOR
STEERING COLUMN VERTICAL ADJUSTMENT MOTOR
STEERING COLUMN VERTICAL ADJUSTMENT SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
Go to component -> Power tilt steering column circuit -> STEERING COLUMN VERTICAL ADJUSTMENT SENSOR
