Audi Q5 e-tron I (2022-2024) right seat bolster heating for left front seat Wiring diagrams
This page contains all the electrical diagrams for the component. right seat bolster heating for left front seat, in which he is found in the car Audi Q5 e-tron I (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right seat bolster heating for left front seat (1 of 3)
48 V BATTERY
ANTENNA AMPLIFIER
AUXILIARY BATTERY
BLK WIRE
BLU WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
COUPLING POINT IN LEFT REAR SEAT
COUPLING POINT ON INSTRUMENT PANEL, CENTER
COUPLING STATION IN LEFT FRONT SEAT
DRIVER SEAT BACKREST COUPLING POINT
DRIVER SEAT BELT TENSIONER IGNITER 2
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
INFORMATION ELECTRONICS CONTROL MODULE 1
LATE PRODUCTION
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT EXTENSION HEATING ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATING ELEMENT, LEFT FRONT SEAT TEMPERATURE SENSOR
LEFT LUGGAGE COMPARTMENT LAMP
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT, LEFT REAR HEATED SEAT TEMPERATURE SENSOR
LEFT REAR FOOTWELL LAMP
LEFT REAR SEAT COUPLING STATION
NCA WIRE
NEAR FIELD COMMUNICATION CONTROL MODULE 2
REAR A/C DISPLAY CONTROL HEAD
RIGHT LUGGAGE COMPARTMENT LAMP
RIGHT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT
STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
W/ AUXILIARY LAMPS
WHT WIRE
WINDSHIELD DEFOGGER
Go to component -> Ground distribution circuit (5 of 10) -> RIGHT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT
