Audi Q5 e-tron I (2022-2024) right luggage compartment lamp Wiring diagrams

48 V BATTERY ANTENNA AMPLIFIER AUXILIARY BATTERY BLK WIRE BLU WIRE BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COUPLING POINT IN LEFT REAR SEAT COUPLING POINT ON INSTRUMENT PANEL, CENTER COUPLING STATION IN LEFT FRONT SEAT DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT BELT TENSIONER IGNITER 2 IGNITION COIL 1 W/ POWER OUTPUT STAGE IGNITION COIL 2 W/ POWER OUTPUT STAGE IGNITION COIL 3 W/ POWER OUTPUT STAGE INFORMATION ELECTRONICS CONTROL MODULE 1 LATE PRODUCTION LEFT FRONT SEAT COUPLING STATION LEFT FRONT SEAT EXTENSION HEATING ELEMENT LEFT FRONT SEAT HEATED BACKREST LEFT FRONT SEAT HEATING ELEMENT, LEFT FRONT SEAT TEMPERATURE SENSOR LEFT LUGGAGE COMPARTMENT LAMP LEFT REAR BACKREST HEATING ELEMENT LEFT REAR BENCH SEAT HEATING ELEMENT, LEFT REAR HEATED SEAT TEMPERATURE SENSOR LEFT REAR FOOTWELL LAMP LEFT REAR SEAT COUPLING STATION NCA WIRE NEAR FIELD COMMUNICATION CONTROL MODULE 2 REAR A/C DISPLAY CONTROL HEAD RIGHT LUGGAGE COMPARTMENT LAMP RIGHT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE W/ AUXILIARY LAMPS WHT WIRE WINDSHIELD DEFOGGER

BLU/BRN WIRE BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER DOOR CONTROL MODULE (RIGHT FRONT DOOR) FRONT PASSENGER EXTERIOR DOOR HANDLE ILLUMINATION LAMP FRONT PASSENGER INTERIOR LOCKING BUTTON FRONT PASSENGER POWER WINDOW BUTTON FRONT PASSENGER SEAT MEMORY SETTINGS CONTROL HEAD FUSE 11 FUSE 14 FUSE 5 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL B FUSE PANEL C GRY/RED WIRE HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH LEFT FRONT DOOR COUPLING POINT LIGHT SWITCH ORG/BRN WIRE ORG/GRN WIRE PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP POWER DISTRIBUTION SYSTEM RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 RIGHT FRONT DOOR COUPLING POINT RIGHT LUGGAGE COMPARTMENT LAMP VIO/WHT WIRE WHT/RED WIRE YEL WIRE
