Audi Q5 e-tron I (2022-2024) rear lid lock button in luggage compartment Wiring diagrams

48 V BATTERY BATTERY REGULATION CONTROL MODULE BRN WIRE CENTER COUPLING POINT ON REAR LID COMFORT SYSTEM CENTRAL CONTROL MODULE COUPLING POINT IN LUGGAGE COMPARTMENT, LEFT DIGITAL SOUND SYSTEM CONTROL MODULE EXHAUST DOOR CONTROL UNIT 2 HIGH MOUNT BRAKE LIGHT HIGH-VOLTAGE BATTERY CHARGER 1 HIGH-VOLTAGE BATTERY COUPLING POINT HIGH-VOLTAGE BATTERY REGULATION COUPLING POINT 1 HYBRID BATTERY UNIT LANE CHANGE ASSISTANCE CONTROL MODULE LANE CHANGE ASSISTANCE CONTROL MODULE 2 LEFT LICENSE PLATE LAMP LEFT TAIL LAMP LEFT TAIL LAMP 2 PERIPHERAL CAMERA CONTROL MODULE REAR BUMPER COUPLING POINT 1 REAR LID CLOSING AID REAR LID CONTROL HEAD REAR LID LAMP REAR LID LOCK BUTTON IN LUGGAGE COMPARTMENT REAR LID LOCK UNIT REAR LID OPENER CONTROL MODULE REAR VIEW CAMERA SYSTEM CONTROL MODULE REAR WINDOW DEFOGGER RELAY REAR WINDOW WIPER MOTOR RELEASE BUTTON IN REAR LID HANDLE REMOTE START A/C RELAY RIGHT LICENSE PLATE LAMP RIGHT TAIL LAMP RIGHT TAIL LAMP 2 WINDSHIELD DEFOGGER RELAY

BLK WIRE BLU/BRN WIRE BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE (LEFT FRONT DOOR) DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER INTERIOR LOCKING BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE EXTERIOR DOOR HANDLE ILLUMINATION LAMP DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP DRIVER SIDE REAR INTERIOR DOOR HANDLE ILLUMINATION BULB DRIVER SIDE REAR INTERIOR LOCKING BUTTON DRIVER SIDE REAR POWER WINDOW BUTTON GRN/BRN WIRE INTERIOR MONITORING, VEHICLE INCLINATION DEACTIVATION BUTTON LEFT LUGGAGE COMPARTMENT LAMP LEFT REAR DOOR COUPLING POINT MIRROR ADJUSTING SWITCH ORG/BRN WIRE ORG/GRN WIRE REAR LID CONTROL HEAD REAR LID LAMP REAR LID LOCK BUTTON IN LUGGAGE COMPARTMENT REAR LID REMOTE RELEASE BUTTON RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE VIO/WHT WIRE W/ AUXILIARY LAMPS WHT/RED WIRE YEL WIRE
