Audi Q5 e-tron I (2022-2024) radiator fan control module 2 Wiring diagrams
This page contains all the electrical diagrams for the component. radiator fan control module 2, in which he is found in the car Audi Q5 e-tron I (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram radiator fan control module 2 (1 of 3)
2.0L TURBO HYBRID DMSA
2.0L TURBO HYBRID DPVA, 3.0L TURBO
3.0L TURBO
BLK/GRY WIRE
BLK/RED WIRE
BRN WIRE
BRN/GRN WIRE
COOLANT RECIRCULATION PUMP
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
FUSE 2
FUSE 3
FUSE PANEL A
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LEFT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
SUPPRESSOR
THERMAL MANAGEMENT CONTROL MODULE
VIO/WHT WIRE
W/O TRAILER HITCH
WHT/BLU WIRE
WHT/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit, w/ climatronic (3 of 4) -> RADIATOR FAN CONTROL MODULE 2
Wiring diagram radiator fan control module 2 (2 of 3)
2.0L TURBO HYBRID DMSA
2.0L TURBO HYBRID DPVA, 3.0L TURBO
3.0L TURBO
BLK/GRY WIRE
BLK/RED WIRE
BRN WIRE
BRN/GRN WIRE
COOLANT RECIRCULATION PUMP
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
FUSE 2
FUSE 3
FUSE PANEL A
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LEFT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
SUPPRESSOR
THERMAL MANAGEMENT CONTROL MODULE
VIO/WHT WIRE
W/O TRAILER HITCH
WHT/BLU WIRE
WHT/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit, w/o climatronic (4 of 5) -> RADIATOR FAN CONTROL MODULE 2
Wiring diagram radiator fan control module 2 (3 of 3)
2.0L TURBO HYBRID DMSA
2.0L TURBO HYBRID DPVA, 3.0L TURBO
3.0L TURBO
BLK/GRY WIRE
BLK/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
COOLANT RECIRCULATION PUMP
ENGINE COOLANT LEVEL SENSOR
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
FUSE 2
FUSE 3
FUSE PANEL A
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LEFT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT
ORG/BRN WIRE
OUTSIDE AIR TEMPERATURE SENSOR
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
SUPPRESSOR
THERMAL MANAGEMENT CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
W/O TRAILER HITCH
WHT/BLU WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Cooling fan circuit (1 of 2) -> RADIATOR FAN CONTROL MODULE 2
