Audi Q5 e-tron I (2022-2024) oil pressure/ temperature sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.oil pressure/ temperature sensor 2, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oil pressure/ temperature sensor 2 (1 of 1)
ALL WHEEL DRIVE CLUTCH VALVE
ALL WHEEL DRIVE CLUTCH VALVE 2
ALL WHEEL DRIVE PUMP
BLK WIRE
BLK/VIO WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DIFFERENTIAL LOCK CONTROL MODULE
FUSE 10
FUSE PANEL 5
FUSE PANEL F
GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
OIL PRESSURE/ TEMPERATURE SENSOR
OIL PRESSURE/ TEMPERATURE SENSOR 2
PNK WIRE
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 2
SUPPLEMENTAL RESTRAINTS SYSTEM
VIO/RED WIRE
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Awd circuit, w/ torque vectoring -> OIL PRESSURE/ TEMPERATURE SENSOR 2
