Audi Q5 e-tron I (2022-2024) near field communication antenna Wiring diagram
This page shows the only wiring diagram for the component.near field communication antenna, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram near field communication antenna (1 of 1)
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CENTER CONSOLE NEAR FIELD COMMUNICATION ANTENNA 2
CENTER COUPLING POINT ON INSTRUMENT PANEL
COMPUTER DATA LINES SYSTEM
DISPLAY UNIT
GRN WIRE
GRY WIRE
INSTRUMENT CLUSTER CONTROL MODULE
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT EXTERIOR DOOR HANDLE TOUCH SENSOR
LUGGAGE COMPARTMENT ACCESS/START SYSTEM ANTENNA
NCA WIRE
NEAR FIELD COMMUNICATION ANTENNA
NEAR FIELD COMMUNICATION CONTROL MODULE
NEAR FIELD COMMUNICATION CONTROL MODULE 2
ORG/BRN WIRE
ORG/VIO WIRE
RED WIRE
RED/BLU WIRE
RIGHT ACCESS/START AUTHORIZATION ANTENNA
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT EXTERIOR DOOR HANDLE TOUCH SENSOR
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR
TELEPHONE BASEPLATE
VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA 1
VIO WIRE
W/ TELEPHONE SYSTEM
W/O TELEPHONE SYSTEM
WHT WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Access/start circuit (2 of 2) -> NEAR FIELD COMMUNICATION ANTENNA
