Audi Q5 e-tron I (2022-2024) left multi-function buttons on steering wheel Wiring diagram
This page shows the only wiring diagram for the component.left multi-function buttons on steering wheel, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left multi-function buttons on steering wheel (1 of 1)
4-PIN CONNECTOR
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 12
FUSE PANEL C
GRN WIRE
HEATED STEERING WHEEL
HEATED STEERING WHEEL SENSOR
HOT AT ALL TIMES
LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
PNK WIRE
RED WIRE
RED/VIO WIRE
SPIRAL SPRING
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL HEATING BUTTON
VIO WIRE
Go to component -> Heated steering wheel circuit -> LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
