Audi Q5 e-tron I (2022-2024) left headlamp beam adjustment motor Wiring diagram
This page shows the only wiring diagram for the component.left headlamp beam adjustment motor, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left headlamp beam adjustment motor (1 of 1)
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE
BLK/BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 11
FUSE 12
FUSE 3
FUSE 9
FUSE PANEL 2
FUSE PANEL 3
FUSE PANEL B
FUSE PANEL C
GRY/RED WIRE
HEADLAMP SWITCH ILLUMINATION BULB
HOT AT ALL TIMES
HUMIDITY SENSOR
INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT FOG LAMP BULB
LEFT FRONT HEADLAMP
LEFT FRONT SIDE MARKER LAMP BULB
LEFT FRONT STRUT TOWER)
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP BEAM ADJUSTMENT MOTOR
LEFT HEADLAMP CURRENT CODING RESISTANCE 1
LEFT HEADLAMP TEMPERATURE SENSOR 1
LEFT HID HEADLAMP BULB
LEFT LIGHT CONTROL MODULE
LEFT LOW BEAM HEADLAMP REFLECTOR MOTOR
LIGHT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
POSITION LAMP INDICATOR LAMP
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY & FUSE PANEL 1
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD PROJECTION HEAD-UP DISPLAY BUTTON
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit, w/ hid (1 of 2) -> LEFT HEADLAMP BEAM ADJUSTMENT MOTOR
