Audi Q5 e-tron I (2022-2024) left front seat heated backrest Wiring diagrams
This page contains all the electrical diagrams for the component. left front seat heated backrest, in which he is found in the car Audi Q5 e-tron I (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front seat heated backrest (1 of 3)
48 V BATTERY
ANTENNA AMPLIFIER
AUXILIARY BATTERY
BLK WIRE
BLU WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
COUPLING POINT IN LEFT REAR SEAT
COUPLING POINT ON INSTRUMENT PANEL, CENTER
COUPLING STATION IN LEFT FRONT SEAT
DRIVER SEAT BACKREST COUPLING POINT
DRIVER SEAT BELT TENSIONER IGNITER 2
IGNITION COIL 1 W/ POWER OUTPUT STAGE
IGNITION COIL 2 W/ POWER OUTPUT STAGE
IGNITION COIL 3 W/ POWER OUTPUT STAGE
INFORMATION ELECTRONICS CONTROL MODULE 1
LATE PRODUCTION
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT EXTENSION HEATING ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATING ELEMENT, LEFT FRONT SEAT TEMPERATURE SENSOR
LEFT LUGGAGE COMPARTMENT LAMP
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT, LEFT REAR HEATED SEAT TEMPERATURE SENSOR
LEFT REAR FOOTWELL LAMP
LEFT REAR SEAT COUPLING STATION
NCA WIRE
NEAR FIELD COMMUNICATION CONTROL MODULE 2
REAR A/C DISPLAY CONTROL HEAD
RIGHT LUGGAGE COMPARTMENT LAMP
RIGHT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT
STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
W/ AUXILIARY LAMPS
WHT WIRE
WINDSHIELD DEFOGGER
Go to component -> Ground distribution circuit (5 of 10) -> LEFT FRONT SEAT HEATED BACKREST
Wiring diagram left front seat heated backrest (2 of 3)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COUPLING POINT IN LEFT REAR SEAT
DRIVER SEAT BACKREST COUPLING POINT
EARLY PRODUCTION
FRONT A/C DISPLAY CONTROL HEAD
FUSE 1
FUSE 6
FUSE 8
FUSE PANEL 1
FUSE PANEL 3
FUSE PANEL B
FUSE PANEL C
FUSE PANEL F
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
LATE PRODUCTION
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT EXTENSION HEATING ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATING ELEMENT, LEFT FRONT SEAT TEMPERATURE SENSOR
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR BENCH SEAT HEATING ELEMENT, LEFT REAR HEATED SEAT TEMPERATURE SENSOR
LEFT REAR SEAT COUPLING STATION
LEFT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT
LEFT SEAT HEATING BUTTON
ORG/BRN WIRE
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
RELAY & FUSE PANEL 2
RIGHT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT
RIGHT SEAT HEATING BUTTON
VIO/WHT WIRE
W/ SEAT DEPTH ADJUSTMENT
WHT/BRN WIRE
WHT/YEL WIRE
Go to component -> Heated seats circuit, w/o ventilation (1 of 2) -> LEFT FRONT SEAT HEATED BACKREST
Wiring diagram left front seat heated backrest (3 of 3)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
DRIVER SEAT BACKREST COUPLING POINT
EARLY PRODUCTION
FUSE 1
FUSE PANEL 3
FUSE PANEL 4
FUSE PANEL B
GRN WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LATE PRODUCTION
LEFT FRONT SEAT BACKREST FAN 1
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT CUSHION FAN 1
LEFT FRONT SEAT EXTENSION HEATING ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATING ELEMENT, LEFT FRONT SEAT TEMPERATURE SENSOR
LEFT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT
REAR A/C DISPLAY CONTROL HEAD
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
REMOTE START A/C RELAY
RIGHT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT
VIO WIRE
VIO/WHT WIRE
W/ SEAT DEPTH ADJUSTMENT
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Heated seats circuit, w/ ventilation (1 of 2) -> LEFT FRONT SEAT HEATED BACKREST
