Audi Q5 e-tron I (2022-2024) left cupholder illumination bulb Wiring diagram
This page shows the only wiring diagram for the component.left cupholder illumination bulb, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left cupholder illumination bulb (1 of 1)
BRN WIRE
COMPUTER DATA LINES SYSTEM
CUPHOLDER AMBIENT LIGHTING LAMP
CUPHOLDER COOLING ELEMENT BUTTON
CUPHOLDER COOLING INDICATOR LAMP
CUPHOLDER HEATING ELEMENT BUTTON
CUPHOLDER HEATING INDICATOR LAMP
CUPHOLDER W/ HEATING, COOLING ELEMENT
FUSE 9
FUSE PANEL 3
FUSE PANEL F
HOT AT ALL TIMES
LEFT CUPHOLDER ILLUMINATION BULB
RED/BLU WIRE
RELAY & FUSE PANEL 2
RIGHT CUPHOLDER ILLUMINATION BULB
VIO/RED WIRE
Go to component -> Heated & cooled cup holder circuit -> LEFT CUPHOLDER ILLUMINATION BULB
