Audi Q5 e-tron I (2022-2024) front passenger massage function button Wiring diagrams

ANTENNA AMPLIFIER SHIELD BLU WIRE BRN WIRE COUPLING POINT IN RIGHT REAR SEAT COUPLING POINT IN THE RIGHT REAR DOOR DATA BUS ON BOARD DIAGNOSTIC INTERFACE DIFFERENTIAL LOCK CONTROL MODULE EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE FRONT PASSENGER MASSAGE FUNCTION BUTTON FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL MODULE FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT BELT TENSIONER IGNITER 2 FRONT PASSENGER SEAT SWITCH MODULE FRONT PASSENGER SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP FRONT PASSENGER THORAX AIR BAG IGNITER FUEL DELIVERY UNIT FUEL PUMP CONTROL MODULE LEFT FRONT LUMBAR SUPPORT ADJUSTMENT SWITCH LEVEL CONTROL SYSTEM COMPRESSOR MOTOR PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR DOOR LOCK UNIT PASSENGER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP REAR WINDOW BREAKAGE SENSOR RIGHT FRONT SEAT BACKREST FAN 1 RIGHT FRONT SEAT BELT RIGHT FRONT SEAT BELT TENSIONER CONTROL MODULE RIGHT FRONT SEAT COUPLING STATION RIGHT FRONT SEAT CUSHION FAN 1 RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR BRAKE PAD WEAR SENSOR RIGHT REAR DOOR AMBIENT ILLUMINATION BULB 1 RIGHT REAR DOOR CONTOUR ILLUMINATION LAMP RIGHT REAR DOOR COUPLING POINT RIGHT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR RIGHT REAR FOOTWELL LAMP RIGHT REAR HEATED SEAT TEMPERATURE SENSOR, RIGHT REAR BENCH SEAT HEATING ELEMENT RIGHT REAR INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE RIGHT REAR SEAT COUPLING STATION W/ AUXILIARY LAMPS WHT WIRE

BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER MULTI- CONTOUR SEAT CONTROL MODULE DRIVER MULTI-CONTOUR SEAT COMPRESSOR DRIVER SEAT BACKREST COUPLING POINT DRIVER SEAT BOLSTER/ BACKREST INFLATION ADJUSTMENT VALVE BLOCK DRIVER SEAT SWITCH MODULE DRIVER SIDE MASSAGE FUNCTION BUTTON FRONT PASSENGER MASSAGE FUNCTION BUTTON FRONT PASSENGER MULTI-CONTOUR SEAT COMPRESSOR FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL MODULE FRONT PASSENGER SEAT BACKREST COUPLING POINT FRONT PASSENGER SEAT BOLSTER/ BACKREST INFLATION ADJUSTMENT VALVE BLOCK FRONT PASSENGER SEAT SWITCH MODULE FUSE 3 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL B FUSE PANEL F GRN WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT FRONT SEAT COUPLING STATION RED WIRE RED/BLK WIRE RELAY & FUSE PANEL 1 RELAY & FUSE PANEL 2 RIGHT FRONT SEAT COUPLING STATION VIO WIRE W/ POWER SEAT ADJUSTMENT W/O POWER SEAT ADJUSTMENT WHT/RED WIRE
