Audi Q5 e-tron I (2022-2024) exhaust door control unit 2 Wiring diagram
This page shows the only wiring diagram for the component.exhaust door control unit 2, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exhaust door control unit 2 (1 of 1)
48 V BATTERY
BATTERY REGULATION CONTROL MODULE
BRN WIRE
CENTER COUPLING POINT ON REAR LID
COMFORT SYSTEM CENTRAL CONTROL MODULE
COUPLING POINT IN LUGGAGE COMPARTMENT, LEFT
DIGITAL SOUND SYSTEM CONTROL MODULE
EXHAUST DOOR CONTROL UNIT 2
HIGH MOUNT BRAKE LIGHT
HIGH-VOLTAGE BATTERY CHARGER 1
HIGH-VOLTAGE BATTERY COUPLING POINT
HIGH-VOLTAGE BATTERY REGULATION COUPLING POINT 1
HYBRID BATTERY UNIT
LANE CHANGE ASSISTANCE CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE 2
LEFT LICENSE PLATE LAMP
LEFT TAIL LAMP
LEFT TAIL LAMP 2
PERIPHERAL CAMERA CONTROL MODULE
REAR BUMPER COUPLING POINT 1
REAR LID CLOSING AID
REAR LID CONTROL HEAD
REAR LID LAMP
REAR LID LOCK BUTTON IN LUGGAGE COMPARTMENT
REAR LID LOCK UNIT
REAR LID OPENER CONTROL MODULE
REAR VIEW CAMERA SYSTEM CONTROL MODULE
REAR WINDOW DEFOGGER RELAY
REAR WINDOW WIPER MOTOR
RELEASE BUTTON IN REAR LID HANDLE
REMOTE START A/C RELAY
RIGHT LICENSE PLATE LAMP
RIGHT TAIL LAMP
RIGHT TAIL LAMP 2
WINDSHIELD DEFOGGER RELAY
Go to component -> Ground distribution circuit (7 of 10) -> EXHAUST DOOR CONTROL UNIT 2
