Audi Q5 e-tron I (2022-2024) driver side exterior door handle illumination lamp Wiring diagram
This page shows the only wiring diagram for the component.driver side exterior door handle illumination lamp, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side exterior door handle illumination lamp (1 of 1)
BLK WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE (LEFT FRONT DOOR)
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER INTERIOR LOCKING BUTTON
DRIVER SEAT MEMORY SETTINGS CONTROL HEAD
DRIVER SIDE EXTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP
DRIVER SIDE REAR INTERIOR DOOR HANDLE ILLUMINATION BULB
DRIVER SIDE REAR INTERIOR LOCKING BUTTON
DRIVER SIDE REAR POWER WINDOW BUTTON
GRN/BRN WIRE
INTERIOR MONITORING, VEHICLE INCLINATION DEACTIVATION BUTTON
LEFT LUGGAGE COMPARTMENT LAMP
LEFT REAR DOOR COUPLING POINT
MIRROR ADJUSTING SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID CONTROL HEAD
REAR LID LAMP
REAR LID LOCK BUTTON IN LUGGAGE COMPARTMENT
REAR LID REMOTE RELEASE BUTTON
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
VIO/WHT WIRE
W/ AUXILIARY LAMPS
WHT/RED WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (3 of 4) -> DRIVER SIDE EXTERIOR DOOR HANDLE ILLUMINATION LAMP
