Audi Q5 e-tron I (2022-2024) child safety lock motor Wiring diagrams

This page contains all the electrical diagrams for the component. child safety lock motor, in which he is found in the car Audi Q5 e-tron I (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram child safety lock motor (1 of 4)

Wiring diagram child safety lock motor for Audi Q5 e-tron I (2022-2024) (1 of 4)

Get access

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE CENTRAL LOCKING SAFE MOTOR CENTRAL LOCKING SYSTEM ACTUATOR CENTRAL LOCKING SYSTEM MOTOR CHILD SAFETY LOCK CONTACT SWITCH CHILD SAFETY LOCK MOTOR COMPUTER DATA LINES SYSTEM CONTACT SWITCH DRIVER SIDE REAR DOOR CONTROL MODULE (LEFT REAR DOOR) GRN/BLK WIRE GRN/VIO WIRE GRY/BLU WIRE GRY/VIO WIRE INSTRUMENT CLUSTER CONTROL MODULE LEFT FRONT DOOR COUPLING POINT LEFT REAR DOOR COUPLING POINT LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR ORG/BRN WIRE ORG/VIO WIRE RED/BLU WIRE VIO/BLU WIRE VIO/GRY WIRE VIO/RED WIRE W/ CHILD SAFETY LOCK W/O CHILD SAFETY LOCK YEL WIRE

Go to component -> Forced entry circuit (3 of 5) -> CHILD SAFETY LOCK MOTOR

Wiring diagram child safety lock motor (2 of 4)

Wiring diagram child safety lock motor for Audi Q5 e-tron I (2022-2024) (2 of 4)

Get access

BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE CENTRAL LOCKING SAFE MOTOR CENTRAL LOCKING SYSTEM ACTUATOR CENTRAL LOCKING SYSTEM MOTOR CHILD SAFETY LOCK BUTTON CHILD SAFETY LOCK CONTACT SWITCH CHILD SAFETY LOCK MOTOR CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP CONTACT SWITCH DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER SIDE REAR INTERIOR LOCKING BUTTON GRN/VIO WIRE GRY/BLU WIRE GRY/VIO WIRE LEFT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR INTERIOR LOCKING BUTTON RED/BLU WIRE RIGHT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP RIGHT REAR DOOR VIO/BLU WIRE VIO/GRY WIRE VIO/RED WIRE W/ CHILD SAFETY LOCK W/O CHILD SAFETY LOCK

Go to component -> Forced entry circuit (4 of 5) -> CHILD SAFETY LOCK MOTOR
