Audi Q5 e-tron I (2022-2024) antenna amplifier 2 radio antenna 2 Wiring diagrams
This page contains all the electrical diagrams for the component. antenna amplifier 2 radio antenna 2, in which he is found in the car Audi Q5 e-tron I (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram antenna amplifier 2 radio antenna 2 (1 of 2)
ANTENNA AMPLIFIER 2 RADIO ANTENNA 2
BLK WIRE
BLU/GRY WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT CLUSTER
COMPUTER DATA LINES SYSTEM
DRIVER VOLUME CONTROL
GRY WIRE
GRY/BLK WIRE
LEFT FRONT BASS SPEAKER
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT TREBLE SPEAKER
NCA WIRE
NEAR FIELD COMMUNICATION CONTROL MODULE 2
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT TREBLE SPEAKER
TELEPHONE BASEPLATE
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Navigation circuit, w/o amplifier (3 of 4) -> ANTENNA AMPLIFIER 2 RADIO ANTENNA 2
Wiring diagram antenna amplifier 2 radio antenna 2 (2 of 2)
ANTENNA AMPLIFIER 2 RADIO ANTENNA 2
BLK WIRE
BLU/GRY WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
CENTER COUPLING POINT ON INSTRUMENT CLUSTER
COMPUTER DATA LINES SYSTEM
DRIVER VOLUME CONTROL
GRY WIRE
GRY/BLK WIRE
LEFT FRONT BASS SPEAKER
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT TREBLE SPEAKER
NCA WIRE
NEAR FIELD COMMUNICATION CONTROL MODULE 2
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT TREBLE SPEAKER
TELEPHONE BASEPLATE
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Radio circuit, w/o amplifier (3 of 4) -> ANTENNA AMPLIFIER 2 RADIO ANTENNA 2
