Audi Q5 e-tron I (2022-2024) air conditioning, cooling fans systems Wiring diagram

AIR CONDITIONING, COOLING FANS SYSTEMS BLK WIRE BLK/GRY WIRE BLK/RED WIRE BLU WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE COOLANT LEVEL SENSOR 2 GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/GRN WIRE GRY/WHT WIRE NCA WIRE ORG/BRN WIRE RED WIRE RED/VIO WIRE THERMAL MANAGEMENT CONTROL MODULE (BEHIND LEFT FENDER, ON "A" PILLAR) THERMAL MANAGEMENT COOLANT TEMPERATURE SENSOR 1 THERMAL MANAGEMENT COOLANT TEMPERATURE SENSOR 2 THERMAL MANAGEMENT COOLANT TEMPERATURE SENSOR 3 THERMAL MANAGEMENT COOLANT TEMPERATURE SENSOR 4 THERMAL MANAGEMENT COOLANT TEMPERATURE SENSOR 5 THERMAL MANAGEMENT COOLANT TEMPERATURE SENSOR 6 THERMAL MANAGEMENT COOLANT TEMPERATURE SENSOR 7 THERMAL MANAGEMENT COOLANT TEMPERATURE SENSOR 8 VIO/BLU WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
