Audi Q5 e-tron I (2022-2024) a/c pressure temperature sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.a/c pressure temperature sensor 2, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c pressure temperature sensor 2 (1 of 1)
A/C PRESSURE TEMPERATURE SENSOR 2
A/C PRESSURE/ TEMPERATURE SENSOR
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
FUSE 14
FUSE PANEL 2
FUSE PANEL F
GRN/YEL WIRE
GRY/GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT
NCA WIRE
RED WIRE
RED/BRN WIRE
RED/VIO WIRE
RED/WHT WIRE
REFRIGERANT SHUT-OFF VALVE 2
REFRIGERANT SHUT-OFF VALVE 3
REFRIGERANT SHUT-OFF VALVE 4
RELAY & FUSE PANEL 2
THERMAL MANAGEMENT COOLANT PUMP
THERMAL MANAGEMENT COOLANT PUMP 2
THERMAL MANAGEMENT COOLANT PUMP 4
THERMAL MANAGEMENT COOLANT PUMP RELAY
VIO/WHT WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo hybrid, hybrid system circuit (4 of 8) -> A/C PRESSURE TEMPERATURE SENSOR 2
