Audi Q5 e-tron I (2022-2024) 4-pin connector in the steering wheel Wiring diagram
This page shows the only wiring diagram for the component.4-pin connector in the steering wheel, which is found in the car Audi Q5 e-tron I (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4-pin connector in the steering wheel (1 of 1)
3.0L TURBO
4-PIN CONNECTOR IN THE STEERING WHEEL
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
DRIVER AIR BAG IGNITER
DRIVER AIR BAG RELEASE VALVE IGNITER
ENGINE/MOTOR CONTROL MODULE
FUSE 12
FUSE 16
FUSE PANEL C
GRN WIRE
HEATED STEERING WHEEL
HOT AT ALL TIMES
NCA WIRE
PNK WIRE
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
SIGNAL HORN ACTIVATION
SPIRAL SPRING
STEERING ANGLE SENSOR
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
VIO WIRE
VIO/YEL WIRE
W/ STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
W/O STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
WHT WIRE
WINDSHIELD WIPER INTERMITTENT MODE SWITCH
WINDSHIELD WIPER SWITCH, TURN SIGNAL SWITCH
YEL WIRE
Go to component -> Steering column electronic systems control module circuit (1 of 2) -> 4-PIN CONNECTOR IN THE STEERING WHEEL
