Audi Q4 e-tron I (2021-2024) w/o trailer socket Wiring diagram
This page shows the only wiring diagram for the component.w/o trailer socket, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o trailer socket (1 of 1)
BLK WIRE
BLU WIRE
COUPLING POINT IN INTERIOR
DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
GRN WIRE
GRY WIRE
GRY/RED WIRE
LANE CHANGE ASSISTANCE CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE 2
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT SEAT COUPLING STATION
LT BLU WIRE
MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
PARKING AID CONTROL MODULE
REAR PERIPHERAL CAMERA
VIO/WHT WIRE
W/ TRAILER SOCKET
W/O TRAILER SOCKET
WHT WIRE
Go to component -> Computer data lines circuit (3 of 7) -> W/O TRAILER SOCKET
