Audi Q4 e-tron I (2021-2024) vehicle interior access/start system antenna 1 Wiring diagram
This page shows the only wiring diagram for the component.vehicle interior access/start system antenna 1, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle interior access/start system antenna 1 (1 of 1)
ACCESS/START AUTHORIZATION CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRN WIRE
BURGLARY PROTECTION CONTROL MODULE 2
BURGLARY PROTECTION CONTROL MODULE 3
CENTER COUPLING POINT IN INTERIOR
COMPUTER DATA LINES SYSTEM
DRIVER EXTERIOR DOOR HANDLE
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
FUSE 18
FUSE PANEL C
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT ACCESS/START AUTHORIZATION ANTENNA
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT EXTERIOR DOOR HANDLE COUPLING POINT
LEFT FRONT EXTERIOR DOOR HANDLE TOUCH SENSOR
LUGGAGE COMPARTMENT ACCESS/START SYSTEM ANTENNA
ORG/BRN WIRE
ORG/GRY WIRE
RED/BLK WIRE
RIGHT ACCESS/START AUTHORIZATION ANTENNA
VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA 1
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
Go to component -> Access/start circuit (1 of 2) -> VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA 1
