Audi Q4 e-tron I (2021-2024) signal horn, dual tone horn Wiring diagrams
This page contains all the electrical diagrams for the component. signal horn, dual tone horn, in which he is found in the car Audi Q4 e-tron I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram signal horn, dual tone horn (1 of 2)
A/C COMPRESSOR
A/C RELAY
ABS CONTROL MODULE
ADAPTIVE CRUISE CONTROL MODULE
ALARM HORN
ANTI-THEFT ALARM SYSTEM SENSOR
BLOWER COUPLING POINT
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRAKE BOOSTER
BRN WIRE
BURGLARY PROTECTION CONTROL MODULE 2
COUPLING POINT ON LEFT FRONT BUMPER
FRESH AIR BLOWER CONTROL MODULE
HEADLAMP WASHER SYSTEM PUMP
HEATING ELEMENT (PTC) 3
HIGH VOLTAGE BATTERY COOLANT PUMP
HIGH-VOLTAGE BATTERY WARMING MIXING VALVE
HIGH-VOLTAGE BATTERY WARMING MIXING VALVE 2
LEFT FRONT HEADLAMP
LEFT WASHER NOZZLE HEATER
LOW TEMPERATURE CIRCUIT COOLANT PUMP
RADIATOR BLIND ADJUSTMENT MOTOR
RADIATOR FAN
RIGHT WASHER NOZZLE HEATER
RWD
SIGNAL HORN, DUAL TONE HORN
TRAILER SOCKET
WINDSHIELD DEFOGGER RELAY
WIPER MOTOR CONTROL MODULE
Go to component -> Ground distribution circuit (6 of 6) -> SIGNAL HORN, DUAL TONE HORN
Wiring diagram signal horn, dual tone horn (2 of 2)
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
FUSE 39
FUSE 9
FUSE PANEL B
FUSE PANEL C
HORN RELAY
HORN SIGNAL ACTIVATION
HOT AT ALL TIMES
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
RED WIRE
RED/BRN WIRE
RED/YEL WIRE
SIGNAL HORN, DUAL TONE HORN
SPIRAL SPRING
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL COUPLING POINT IN INTERIOR
STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/WHT WIRE
W/ STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
W/O STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
Go to component -> Horn circuit -> SIGNAL HORN, DUAL TONE HORN
