Audi Q4 e-tron I (2021-2024) right vanity mirror lamp contact switch Wiring diagram
This page shows the only wiring diagram for the component.right vanity mirror lamp contact switch, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right vanity mirror lamp contact switch (1 of 1)
BLK/RED WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
COUPLING POINT ON LEFT REAR LID
DRIVER SIDE REAR ENTRY LAMP
FUSE 13
FUSE PANEL C
GLOVE COMPARTMENT LAMP
GLOVE COMPARTMENT LAMP SWITCH
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT ENTRY LAMP AMBIENT LIGHTING BULB
LEFT ILLUMINATED VANITY MIRROR
LEFT LUGGAGE COMPARTMENT LAMP
LEFT VANITY MIRROR LAMP CONTACT SWITCH
ORG/BRN WIRE
REAR LID CONTROL HEAD
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT ILLUMINATED VANITY MIRROR
RIGHT VANITY MIRROR LAMP CONTACT SWITCH
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/GRN WIRE
VIO/WHT WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Courtesy lamps circuit (1 of 5) -> RIGHT VANITY MIRROR LAMP CONTACT SWITCH
