Audi Q4 e-tron I (2021-2024) right front door ambient lighting bulb 1 Wiring diagram
This page shows the only wiring diagram for the component.right front door ambient lighting bulb 1, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front door ambient lighting bulb 1 (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTACT SWITCH
COUPLING POINT IN RIGHT FRONT DOOR
COUPLING POINT IN THE LEFT FRONT DOOR
DRIVER DOOR CONTROL MODULE
DRIVER DOOR LOCK UNIT
DRIVER SIDE DOOR AMBIENT LIGHTING LAMP
DRIVER SIDE ENTRY LAMP
EMERGENCY CALL BUTTON
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
FRONT ROOF MODULE (RIGHT SIDE OF ROOF CONSOLE)
FUSE 26
FUSE 44
FUSE 9
FUSE PANEL C
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
LEFT FRONT DOOR AMBIENT LIGHTING BULB 1
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT READING LAMP
LEFT FRONT READING LAMP BUTTON
ORG/BRN WIRE
PNK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR AMBIENT LIGHTING BULB 1
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT READING LAMP
RIGHT FRONT READING LAMP BUTTON
ROOF ELECTRONICS CONTROL MODULE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT/BLU WIRE
YEL/GRY WIRE
YEL/WHT WIRE
Go to component -> Courtesy lamps circuit (3 of 5) -> RIGHT FRONT DOOR AMBIENT LIGHTING BULB 1
