Audi Q4 e-tron I (2021-2024) rear window breakage sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.rear window breakage sensor 2, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window breakage sensor 2 (1 of 1)
ANTI-THEFT ALARM SYSTEM W/ INTERIOR MONITORING
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 26
FUSE 3
FUSE 4
FUSE 43
FUSE 67
FUSE 9
FUSE PANEL A
FUSE PANEL C
GRN WIRE
GRY WIRE
GRY/BRN WIRE
HATCHBACK
HEATER
HOT AT ALL TIMES
LEFT COUPLING POINT ON REAR LID
LEFT FRONT DOOR COUPLING POINT
MIRRORS SYSTEM
ORG/BRN WIRE
REAR WINDOW
REAR WINDOW BREAKAGE SENSOR
REAR WINDOW BREAKAGE SENSOR 2
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER 2
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
SPORTBACK
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/BLK WIRE
WINDOW DEFOGGER FOR FRONT SENSOR SYSTEM
Go to component -> Rear defogger & heated mirrors circuit -> REAR WINDOW BREAKAGE SENSOR 2
