Audi Q4 e-tron I (2021-2024) positive terminal high-voltage battery control module Wiring diagram
This page shows the only wiring diagram for the component.positive terminal high-voltage battery control module, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram positive terminal high-voltage battery control module (1 of 1)
BATTERY MODULE CONTROL MODULE (INSIDE HV BATTERY)
BATTERY MODULE CONTROL MODULE 5 (INSIDE HV BATTERY)
BATTERY MODULE CONTROL MODULE 9 (INSIDE HV BATTERY)
BLK WIRE
BLK/YEL WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DC CURRENT CHARGE PROTECTION 1
FRONT HEATING, AIR CONDITIONING COUPLING POINT
GRN/GRY WIRE
GRN/RED WIRE
GRN/WHT WIRE
HEATING ELEMENT (PTC) 3
HIGH VOLTAGE BATTERY 1
HIGH-VOLTAGE BATTERY HIGH-VOLTAGE HEATER TEMPERATURE SENSOR 2
HIGH-VOLTAGE BATTERY POWER OUTPUT PROTECTION 1
HIGH-VOLTAGE HEATER (PTC)
HIGH-VOLTAGE HEATER (PTC) CONTROL MODULE
HIGH-VOLTAGE NETWORK COUPLING POINT
HIGH-VOLTAGE SYSTEM FUSE 2
HV-
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/RED WIRE
POSITIVE TERMINAL HIGH-VOLTAGE BATTERY CONTROL MODULE
RED/GRN WIRE
RWD
VIO/BLU WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
Go to component -> Wiring diagram engine performance electric (5 of 10) -> POSITIVE TERMINAL HIGH-VOLTAGE BATTERY CONTROL MODULE
