Audi Q4 e-tron I (2021-2024) left front exterior door handle coupling point Wiring diagrams
This page contains all the electrical diagrams for the component. left front exterior door handle coupling point, in which he is found in the car Audi Q4 e-tron I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front exterior door handle coupling point (1 of 2)
ACCESS/START AUTHORIZATION CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRN WIRE
BURGLARY PROTECTION CONTROL MODULE 2
BURGLARY PROTECTION CONTROL MODULE 3
CENTER COUPLING POINT IN INTERIOR
COMPUTER DATA LINES SYSTEM
DRIVER EXTERIOR DOOR HANDLE
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
FUSE 18
FUSE PANEL C
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT ACCESS/START AUTHORIZATION ANTENNA
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT EXTERIOR DOOR HANDLE COUPLING POINT
LEFT FRONT EXTERIOR DOOR HANDLE TOUCH SENSOR
LUGGAGE COMPARTMENT ACCESS/START SYSTEM ANTENNA
ORG/BRN WIRE
ORG/GRY WIRE
RED/BLK WIRE
RIGHT ACCESS/START AUTHORIZATION ANTENNA
VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA 1
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
Go to component -> Access/start circuit (1 of 2) -> LEFT FRONT EXTERIOR DOOR HANDLE COUPLING POINT
Wiring diagram left front exterior door handle coupling point (2 of 2)
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRN WIRE
COUPLING POINT ON ROOF
COUPLING STATION IN LEFT FRONT SEAT
DIAGNOSTIC CONNECTION
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR DOOR HANDLE
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT SWITCH MODULE
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER THORAX AIR BAG IGNITER
ELECTRIC TRAILER BRAKE POSITION SENSOR
FRONT ROOF MODULE
FUSE PANEL C
FUSE PANEL C SOCKETS RELAY
GARAGE DOOR OPENER CONTROL MODULE
GRN WIRE
INSTRUMENT CLUSTER
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT ENTRY LAMP AMBIENT LIGHTING BULB
LEFT FRONT EXTERIOR DOOR HANDLE COUPLING POINT
LEFT FRONT FOOTWELL LAMP
LEFT FRONT SEAT COUPLING POINT
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT EXTENSION HEATING ELEMENT
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATER
LEFT REAR DOOR COUPLING POINT
LEFT REAR EXTERIOR DOOR HANDLE
LEFT REAR EXTERIOR DOOR HANDLE COUPLING POINT
LEFT REAR FOOTWELL LAMP
LEFT VANITY MIRROR CONTACT SWITCH
MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE
RAIN/LIGHT RECOGNITION SENSOR
REAR INTERIOR LAMP
RIGHT VANITY MIRROR CONTACT SWITCH
STEERING COLUMN ELECTRONICS CONTROL MODULE
TERMINAL 15 POWER SUPPLY RELAY
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
W/ MEMORY
W/ MEMORY, POWER SEAT ADJUSTER
W/ POWER SEAT ADJUSTER
Go to component -> Ground distribution circuit (4 of 6) -> LEFT FRONT EXTERIOR DOOR HANDLE COUPLING POINT
