Audi Q4 e-tron I (2021-2024) left child safety lock- activated- indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.left child safety lock- activated- indicator lamp, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left child safety lock- activated- indicator lamp (1 of 1)
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
CHILD SAFETY LOCK BUTTON
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER DOOR POWER WINDOW CONTROL HEAD
DRIVER POWER WINDOW BUTTON
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR POWER WINDOW BUTTON
DRIVER SIDE REAR WINDOW REGULATOR MOTOR
DRIVER WINDOW REGULATOR MOTOR
EARLY PRODUCTION
FRONT PASSENGER POWER WINDOW BUTTON
FUSE 26
FUSE 9
FUSE PANEL C
GRN WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LATE PRODUCTION
LEFT CHILD SAFETY LOCK BUTTON
LEFT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
LEFT FRONT DOOR COUPLING POINT
LEFT REAR DOOR COUPLING POINT
ORG/BRN WIRE
PASSENGER SIDE REAR POWER WINDOW BUTTON
PUSH BUTTON ILLUMINATION BULB
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT CHILD SAFETY LOCK BUTTON
RIGHT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
RIGHT FRONT DOOR COUPLING POINT
RIGHT REAR DOOR COUPLING POINT
Go to component -> Power windows circuit (1 of 2) -> LEFT CHILD SAFETY LOCK- ACTIVATED- INDICATOR LAMP
