Audi Q4 e-tron I (2021-2024) fresh, air recirculation door coupling point Wiring diagram
This page shows the only wiring diagram for the component.fresh, air recirculation door coupling point, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fresh, air recirculation door coupling point (1 of 1)
A/C COMPRESSOR CONTROL MODULE
BLK/BLU WIRE
BLK/YEL WIRE
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRN WIRE
BRN/BLU WIRE
ELECTRICAL A/C COMPRESSOR
FRESH AIR/RECIRCULATION DOOR (RIGHT SIDE OF A/C UNIT)
FRESH, AIR RECIRCULATION DOOR COUPLING POINT
FRONT SUSPENSION COUPLING POINT
GRN/BLK WIRE
HEATER, A/C UNIT REFRIGERANT SHUT-OFF VALVE
HIGH-VOLTAGE NETWORK WIRE JUNCTION
HIGH-VOLTAGE NETWORK WIRE JUNCTION 2
HIGH-VOLTAGE NETWORK WIRE JUNCTION 3
HIGH-VOLTAGE NETWORK WIRE JUNCTION 4
HIGH-VOLTAGE PTC HEATER
ORG/ WIRE
RED/GRN WIRE
RED/YEL WIRE
RWD
VIO/BLK WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/ HEAT PUMP
WHT WIRE
Go to component -> Automatic a/c circuit (4 of 6) -> FRESH, AIR RECIRCULATION DOOR COUPLING POINT
