Audi Q4 e-tron I (2021-2024) driver side rear door ambient lighting lamp Wiring diagram
This page shows the only wiring diagram for the component.driver side rear door ambient lighting lamp, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side rear door ambient lighting lamp (1 of 1)
BLK/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTACT SWITCH
COUPLING POINT IN THE LEFT REAR DOOR
DRIVER SIDE REAR DOOR AMBIENT LIGHTING LAMP
DRIVER SIDE REAR DOOR CONTROL HEAD
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR DOOR LOCK UNIT
FRONT CENTER CONSOLE AMBIENT LIGHTING BULB 2
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER DOOR LOCK UNIT
FRONT PASSENGER DOOR POWER WINDOW SWITCH
FRONT PASSENGER INTERIOR LOCKING BUTTON
GRN WIRE
GRN/BRN WIRE
GRY/BLU WIRE
GRY/YEL WIRE
INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 1
INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 2
INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 3
LEFT REAR DOOR AMBIENT LIGHTING BULB 1
LEFT REAR DOOR COUPLING POINT
ORG/BRN WIRE
PASSENGER SIDE DOOR AMBIENT LIGHTING LAMP
PASSENGER SIDE ENTRY LAMP
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
VIO/GRN WIRE
Go to component -> Courtesy lamps circuit (4 of 5) -> DRIVER SIDE REAR DOOR AMBIENT LIGHTING LAMP
