Audi Q4 e-tron I (2021-2024) drive motor 2 rotor position sensor 1 Wiring diagrams
This page contains all the electrical diagrams for the component. drive motor 2 rotor position sensor 1, in which he is found in the car Audi Q4 e-tron I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram drive motor 2 rotor position sensor 1 (1 of 2)
ANTI-LOCK BRAKES SYSTEM
BATTERY REGULATION CONTROL MODULE
BLK WIRE
BLK/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE MOTOR 2 ROTOR POSITION SENSOR 1
DRIVE MOTOR INVERTER 2
DRIVE MOTOR TEMPERATURE SENSOR 2
ELECTRIC DRIVE CONTROL MODULE 2
ELECTRIC DRIVE MOTOR 2
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS 2
FUSE 3
FUSE 61
FUSE PANEL B
FUSE PANEL C
GRY/BLK WIRE
GRY/BLU WIRE
HIGH VOLTAGE BATTERY 1
HIGH-VOLTAGE NETWORK WIRE JUNCTION 5
HIGH-VOLTAGE NETWORK WIRE JUNCTION 6
HOT AT ALL TIMES
HV+ HV-
HV-
INTERMEDIATE CIRCUIT CAPACITOR 2
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
RED/GRN WIRE
THREE-PHASE CURRENT DRIVE 2
Go to component -> Front axle circuit -> DRIVE MOTOR 2 ROTOR POSITION SENSOR 1
Wiring diagram drive motor 2 rotor position sensor 1 (2 of 2)
ANTI-LOCK BRAKES SYSTEM
BATTERY REGULATION CONTROL MODULE
BLK WIRE
BLK/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE MOTOR 2 ROTOR POSITION SENSOR 1
DRIVE MOTOR INVERTER
DRIVE MOTOR TEMPERATURE SENSOR
ELECTRIC DRIVE CONTROL MODULE
ELECTRIC DRIVE MOTOR
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS
ELECTRIC DRIVE POWER, CONTROL ELECTRONICS 2
FUSE 3
FUSE 61
FUSE PANEL B
FUSE PANEL C
GRY/RED WIRE
GRY/WHT WIRE
HGH-VOLTAGE BATTERY 1
HIGH-VOLTAGE NETWORK WIRE JUNCTION 5
HIGH-VOLTAGE NETWORK WIRE JUNCTION 6
HOT AT ALL TIMES
HV-
INTERMEDIATE CIRCUIT CAPACITOR 1
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
REAR SUSPENSION COUPLING POINT
RED/GRN WIRE
RWD
THREE-PHASE CURRENT DRIVE
Go to component -> Rear axle circuit -> DRIVE MOTOR 2 ROTOR POSITION SENSOR 1
