Audi Q4 e-tron I (2021-2024) coupling point on left rear lid Wiring diagrams

BLK/RED WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT REAR LID DRIVER SIDE REAR ENTRY LAMP FUSE 13 FUSE PANEL C GLOVE COMPARTMENT LAMP GLOVE COMPARTMENT LAMP SWITCH GRN WIRE GRY WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT ENTRY LAMP AMBIENT LIGHTING BULB LEFT ILLUMINATED VANITY MIRROR LEFT LUGGAGE COMPARTMENT LAMP LEFT VANITY MIRROR LAMP CONTACT SWITCH ORG/BRN WIRE REAR LID CONTROL HEAD RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RIGHT ILLUMINATED VANITY MIRROR RIGHT VANITY MIRROR LAMP CONTACT SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/GRN WIRE VIO/WHT WIRE YEL/BLU WIRE YEL/VIO WIRE

BLK/BRN WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON LEFT REAR LID COUPLING POINT ON ROOF COURTESY LAMPS CIRCUIT DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER INTERIOR LOCKING BUTTON DRIVER INTERIOR LOCKING INDICATOR LAMP DRIVER SEAT MEMORY SETTINGS CONTROL HEAD EXTERIOR REAR VIEW MIRROR ADJUSTER FUSE 13 FUSE 26 FUSE 9 FUSE PANEL C GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES ORG/BRN WIRE PUSH BUTTON ILLUMINATION BULB REAR INTERIOR LAMP REAR LID CONTROL HEAD REAR LID REMOTE RELEASE BUTTON RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE USB CHARGING SOCKET 1 USB CONNECTION 1 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE YEL/RED WIRE
