Audi Q4 e-tron I (2021-2024) coupling point in interior, center Wiring diagram
This page shows the only wiring diagram for the component.coupling point in interior, center, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coupling point in interior, center (1 of 1)
ABS CONTROL MODULE
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COUPLING POINT IN INTERIOR IN THE STEERING WHEEL
COUPLING POINT IN INTERIOR, BOTTOM RIGHT
COUPLING POINT IN INTERIOR, CENTER
DOWNSHIFT PADDLE SWITCH
DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT 1
FUSE 39
FUSE 42
FUSE PANEL C
GRN/GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
ILLUMINATION CONTROL HEAD
LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
PARKING LOCK BUTTON
REAR SUSPENSION COUPLING POINT
RED WIRE
RED/YEL WIRE
RIGHT MULTI-FUNCTION BUTTONS
SELECTOR LEVER
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
SIGNAL HORN ACTIVATION
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
UPSHIFT PADDLE SWITCH
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/ STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
W/O STEERING WHEEL TOUCH RECOGNITION CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> A/t circuit -> COUPLING POINT IN INTERIOR, CENTER
