Audi Q4 e-tron I (2021-2024) brake booster temperature sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.brake booster temperature sensor 2, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake booster temperature sensor 2 (1 of 1)
BLK/RED WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRAKE BOOSTER
BRAKE BOOSTER CONTROL MODULE
BRAKE BOOSTER TEMPERATURE SENSOR 1
BRAKE BOOSTER TEMPERATURE SENSOR 2
BRAKE BOOSTER TEMPERATURE SENSOR 3
BRAKE FLUID LEVEL WARNING SWITCH
BRAKE PEDAL POSITION SENSOR 2
BRN WIRE
BRN/WHT WIRE
CENTER COUPLING POINT IN INTERIOR
COMPUTER DATA LINES SYSTEM
DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT 1
ELECTRO-MECHANICAL BRAKE BOOSTER MOTOR
ENGINE/MOTOR CONTROL MODULE
FRONT SUSPENSION COUPLING POINT
FUSE 44
FUSE PANEL C
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/WHT WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT PARKING BRAKE MOTOR
TOWING RECOGNITION CONTROL MODULE
VIO/GRN WIRE
WHT WIRE
Go to component -> Anti-lock brakes circuit (3 of 3) -> BRAKE BOOSTER TEMPERATURE SENSOR 2
