Audi Q4 e-tron I (2021-2024) automatic light control indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.automatic light control indicator lamp, which is found in the car Audi Q4 e-tron I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic light control indicator lamp (1 of 1)
AUTOMATIC HIGH BEAM BUTTON
AUTOMATIC LIGHT CONTROL INDICATOR LAMP
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE REAR DOOR CONTROL HEAD
DRIVER SIDE REAR DOOR CONTROL MODULE
FUSE 44
FUSE PANEL C
GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
ILLUMINATION CONTROL HEAD
LEFT REAR DOOR COUPLING POINT
LIGHT SWITCH
LOW BEAM BUTTON
LOW BEAM INDICATOR LAMP
ORG/BRN WIRE
PASSENGER SIDE REAR DOOR CONTROL HEAD
PASSENGER SIDE REAR DOOR CONTROL MODULE
PUSH BUTTON ILLUMINATION BULB
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR DOOR COUPLING POINT
VIO/GRN WIRE
Go to component -> Instrument illumination circuit (3 of 3) -> AUTOMATIC LIGHT CONTROL INDICATOR LAMP
