Shift interlock circuit for Audi Q3 II (2018-2024)
Shift interlock circuit
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/VIO WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRAKE LAMP SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE/MOTOR CONTROL MODULE
FUSE 3
FUSE 6
FUSE PANEL B
FUSE PANEL C
GRY/GRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
IGNITION SWITCH KEY LOCK SOLENOID
ORG/BRN WIRE
SELECTOR LEVER
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
TOWING RECOGNITION CONTROL MODULE
TRANSMISSION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT/RED WIRE
YEL/RED WIRE
