Emergency call circuit for Audi Q3 II (2018-2024)
Emergency call circuit (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL BUTTON
EMERGENCY CALL MODULE ANTENNA
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FRONT ROOF MODULE (CENTER FRONT OF ROOF CONSOLE)
FUSE 33
FUSE PANEL C
GPS ANTENNA
GRN WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
LEFT FRONT MICROPHONE
NCA WIRE
ORG/BRN WIRE
RIGHT FRONT MICROPHONE
ROAD SIDE ASSISTANCE BUTTON
ROOF ANTENNA
ROOF ELECTRONICS CONTROL MODULE
TELEMATICS EMERGENCY BATTERY
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/BRN WIRE
YEL/RED WIRE
Emergency call circuit (2 of 2)
AIR BAG CONTROL MODULE
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL MODULE ANTENNA 2
EMERGENCY CALL MODULE SPEAKER
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FUSE 17
FUSE PANEL C
GRN WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
NCA WIRE
ORG/BRN WIRE
SEATS SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
